Camera System

• Dual 48MP camera lenses with combined high-pixel output

• 4K max resolution @ 30fps, 1080p @ 60fps

• 120° DFOV | 110° HFOV | 54° VFOV for wide room coverage

• 6x digital zoom & electronic gimbal for smooth framing

• AI-Powered Features: IntelliFocus, Auto Framing, Speaker Tracking, People Counting, Smart Gallery (Zoom only), Picture-in-Picture

• Privacy cover: Electric lens cap

Audio System

• Speakers: 2 × 10W stereo speakers (max SPL 112dBSPL @0.1m)

• Microphones: Built-in 8 MEMS mic array

  • Pickup distance: 6m (4m for optimal quality)

  • Full-duplex audio with AI noise reduction & dereverberation

• Supports up to 2 additional expansion microphones

Operating System & Intelligence

• OS: Android 13 (upgradeable)

• Microsoft MDEP compatibility for secure deployment

• AI-driven enhancements for smart meetings

Network & Connectivity

• Wi-Fi 6 (2.4G/5G, 802.11 a/b/g/n/ac/ax, 2×2 MIMO)

• Bluetooth 5.0

• Ethernet port (10/100/1000)

Ports

• 2 × USB-C | 1 × USB 2.0 (Type-A)

• 2 × HDMI-Out

• 1 × Yealink VCH (RJ-45)

• 1 × 3.5mm Line-in & Line-out

• 1 × Power port, Security lock slot, Reset slot

Video & Audio Codecs

• Video: H.264 High Profile, SVC

• Audio: ARES, G.722.1C, G.722.1, G.722, G.711, G.729

Package Contents

• MeetingBar A40

• 2 × HDMI cable, 1 × Network cable

• TV Clip Mount & Wall Mount

• Optional Packages:

  • A40-010: A40 + VCR11

  • A40-031: A40 + CTP25

Environmental Factors

• Operating temperature: 0 – 40°C

• Operating humidity: 10 – 95%

Dimensions & Weight

• Device size: 650 × 62 × 80 mm

• Net weight: 5.54 kg

• Gross weight: 6.09 kg
