Display

• Screen Size: 98″ (247.65 cm)

• Panel Type: IPS with Direct LED

• Resolution: 3840 x 2160 (UHD, 16:9)

• Brightness: 600 cd/m²

• Operation: 24/7

• Bezel Width: 30 mm (all sides)

Connectivity

• HDMI Input: 4 x HDMI

• USB Input: 4 x USB (2 x USB 2.0, 1 x USB 2.0 internal, 1 x Type C)

• DisplayPort: 1 x DP In (1.2a), 1 x DP Out (1.2a)

• VGA: 1 x 15pin D-sub

• Audio: Line In (L/R), M3 Jack, Optical SPDIF

• External Control: RS232 (DE-9F), Ethernet (RJ45), IR Sensor (RJ12)

• Optional Input: OPS Slot (Windows / Android support)

Smart Features

• Built-in HTML5 Browser (Opera 4.9)

• Auto Launch, Scheduler, USB Autoplay

• HDMI CEC & Wake-up

• Panel Lock, Quick Standby, Screen Saver

• Failover Switching, Pixel Shift, OSD Rotation

• Video Wall Support: Up to 10 x 10 configuration

• Real-Time Clock, SNMP v3, Crestron Connected (with backlight command)

Audio & Wireless

• Internal Speakers: 10W x 2

• Wi-Fi: Yes (Dongle, IEEE 802.11 a/b/g/n Dual Band)

• Bluetooth: Yes (v4.2, Dongle – HID, A2DP)

Mechanical

• Dimensions (W x D x H): 223.6 x 9.8 x 129.2 cm

• Weight: 102.3 kg

• VESA Mount: 900 x 600 mm, M8

Power & Environment

• Power Consumption: 346W

• Deep Standby: ≤0.5W

• Power Supply: 110V–240V AC, 50/60Hz

• Operating Temp: 0–40°C

• Operating Humidity: 10%–90%

Certifications & Accessories

• Safety: BIS Certified

• EMC: Class A (3dB margin)

• CE Certified

• Accessories: QSG, Power Cord, Remote Control, IR Receiver, 3 Cable Clampers, IR Holder, Screws
