Display

• Screen Size: 86″ (218.4 cm)

• Backlight Type: Direct-Type LED

• Resolution: 3840 x 2160 (UHD, 16:9)

• Brightness (Typical): 450 cd/m²

• Contrast Ratio (Typical): 1200:1

• Dynamic Contrast Ratio: 40000:1

• Response Time: 8 ms

• Panel Life Time: 30,000 hours

• Viewing Angle: 178° (H/V)

• Glass Type: 4mm Tempered Anti-Glare

• Bezel Width: Bottom: 66 mm | Top/Left/Right: 15 mm

• VESA Mounting: 600 x 400 mm (M8)

Touch Technology

• Type: Infrared (IR)

• Touch Points: 20 (Windows), 10 (Android)

• Input Sensitivity: Finger, Gloved Hand, Pointer

• Pen Type: Battery-less Pen

• Dual Pen Recognition: Yes

• Palm Erase: Yes

• OS Support: Windows (7/8/10), Vista, XP, macOS, Linux, Android

• Connectivity Protocols: HID, TUIO, Flash

Built-in System

• Operating System: Customized Android Pie 9.0

• CPU: CA55 Quad-core

• GPU: Mali470 MP3

• RAM: 2 GB DDR3

• Storage: 8 GB eMMC

• WiFi: WiFi 5 (802.11 a/b/g/n/ac)

• Bluetooth: 4.2

• Ethernet: 10/100 Mbps

Connectivity

• Video Inputs:

  • 4 x HDMI 2.0

  • 2 x USB 2.0 Type-A

  • 1 x USB 2.0 Type-C

  • 1 x MicroSD (Up to 1TB)

  • 1 x Secure USB Slot (USB 2.0)

  • 1 x OPS Slot (15W)

• Video Output: 1 x HDMI 2.0

• Audio Output: Headphone (Line-out), Optical SPDIF

• Front I/Os:

  • 2 x USB 2.0 Type-A

  • 1 x USB 2.0 Type-B (Touch)

  • 1 x HDMI 2.0

• Control Interfaces: RS232 (3.5mm jack), Ethernet (RJ45), Service (RJ12)

• External Sensor: RJ12

• USB-C Port:

  • USB 2.0 Data Transfer

  • Charging: 7.5W

  • DP Alternate Mode: 4K Video

Audio

• Speakers: 2 x 20W (Front-Facing)

• IR Receiver: Fixed on bezel

• Pen Holder: Integrated Magnetic Tray

User Experience & Software

• Homepage: Personalized Background, Navigation Bar, Quick Palette

• Launcher Functions: All Apps, Profile Login/Logout, Quick Settings, Tools, Source Change

• Pre-installed Apps: Whiteboard, ScreenShare, Web Browser, File Manager, Media Player

• Additional Features:

  • Over-the-Air (OTA) Software Update

  • Screen Freeze & Lock

  • Annotate Over Any Source

  • Board Management System

Mechanical

• Product Dimensions (W x H x D): 1962 x 1184 x 97 mm

• Package Dimensions (W x H x D): 2163 x 1405 x 318 mm

• Product Weight: 85.5 kg

• Package Weight: 109.4 kg

Power

• Power Supply: 110–240 VAC

• Current: 2.6 A

• Power Consumption (Typical): 379 W

• Deep Standby Mode: ≤ 0.5 W

Mechanical Features

• Slim Bezel

• User-Friendly Front Controls

• Carry Handles

• Detachable Power Cable

Accessories Included

• Quick Start Guide (QSG)

• Instruction Booklet (IB)

• Power Cord

• Remote Control

• Mounting Kit

• 2 x Stylus Pens

• RS232 Cable

• USB A to B Touch Cable

Certifications

• BIS Certified: Yes
