Display

• Screen Size: 75″ (189.3 cm)

• Backlight Type: Direct-Type LED

• Resolution: 3840 x 2160 (UHD, 16:9)

• Brightness (Typical): 450 cd/m²

• Contrast Ratio: 1200:1 (Typical), 40000:1 (Dynamic)

• Response Time: 8 ms

• Viewing Angle: 178° (H/V)

• Glass Type: 4mm Tempered Anti-Glare, 8H Hardness (Mohs)

• Panel Life: 50,000 hours

• Bezel Width: Bottom: 66 mm | Top/L/R: 15 mm

• VESA Mounting: 600 x 400 mm (M8)

Touch Technology

• Type: Infrared (IR)

• Touch Points: 20 (Windows), 10 (Android)

• Input Methods: Finger, Gloved Hand, Stylus

• Pen Type: Battery-less

• Dual Pen Recognition: Yes

• Palm Erase: Yes

• Touch Interface: USB 2.0

• HID / TUIO / Flash Compatibility: Yes

• Supported OS: Windows 7/8/10, Vista, XP, macOS, Linux, Android

System & OS

• Operating System: Customized Android Pie 9.0

• CPU: CA55 Quad Core

• GPU: Mali470 MP3

• RAM: 2 GB DDR3

• Storage: 8 GB eMMC

• Ethernet: 10/100 Mbps

• Wi-Fi: WiFi 5 (802.11 a/b/g/n/ac)

• Bluetooth: 4.2

Connectivity

• Video Inputs:

  • 4 x HDMI 2.0

  • 2 x USB 2.0 Type-A

  • 1 x USB 2.0 Type-C

  • 1 x MicroSD (Up to 1TB)

  • 1 x USB Secure Slot (USB 2.0)

  • 1 x OPS Slot (15W)

• Video Output: 1 x HDMI 2.0

• Audio Output: Headphone (Line-Out), Optical SPDIF

• Control Interfaces: RS232 (3.5mm), Ethernet (RJ45), Service (RJ12)

• Front I/O Ports:

  • 2 x USB 2.0 Type-A

  • 1 x USB 2.0 Type-B (Touch)

  • 1 x HDMI 2.0

• USB-C Port:

  • USB 2.0 data

  • 7.5W charging

  • 4K video (DP Alt Mode)

Audio

• Speakers: 2 x 20W (Front Facing)

• IR Receiver: Integrated into Bezel

• Pen Holder: Magnetic Tray (Integrated)

User Experience

• Home Screen: Custom Backgrounds, Home Buttons, Navigation

• Launcher: All Apps, Quick Settings, Profile Management

• Built-In Apps: Whiteboard, ScreenShare, Web Browser, Media Player

• Special Features: Screen Freeze, Screen Lock, Annotate Over Source, OTA Updates

Mechanical

• Product Dimensions: 1721 x 1056 x 113 mm

• Package Dimensions: 1990 x 1227 x 265 mm

• Product Weight: 59.3 kg

• Package Weight: 73.8 kg

Power

• Supply Voltage: 110 – 240 VAC

• Current: 2.6 A

• Power Consumption: 231 W (Typical)

• Deep Standby: ≤ 0.5 W

Environmental

• Operating Temperature: 0°C to 40°C

• Humidity: Up to 90%

Mechanical Features

• Slim Bezel

• Front-Facing Controls & Ports

• Detachable Power Cable

• Carry Handles

Accessories (Included)

• Quick Start Guide (QSG)

• Instruction Booklet

• Power Cord

• Remote Control

• Mounting Kit

• 2 x Stylus Pens

• RS232 Cable

• USB A to B Touch Cable

Certifications

• BIS Certified: Yes
