Part Numbers:

• Graphite: 960-001339

• White: 960-001351

Dimensions:

• Height: 91.4 mm

• Width: 719 mm

• Depth: 101 mm

• Lens Depth: 18.5 mm

• Weight: 4.03 kg

Built-in Components:

• PTZ camera

• 6 beamforming microphones

• 3 speakers (1 woofer + 2 midrange)

• AI Viewfinder

• Cable management & retention system

• Integrated table stand

• Logitech CollabOS platform

Certifications & Compatibility:

• Certified for Microsoft Teams Rooms (Android & Windows), Zoom, Google Meet

• Works with most popular video conferencing platforms

Camera:

• Resolutions: 4K, 1440p, 1080p, 900p, 720p, SD @ 30fps

• Pan: ±25° (motorized)

• Tilt: ±15° (motorized)

• Zoom: 4X HD digital zoom

• dFoV: 120° (113° H-FoV / 80.7° V-FoV)

• Total Room Coverage: 163° horizontal x 110° vertical

Speakers:

• Woofer Speaker: 70 mm driver, 8W, 92–99 dB SPL, THD < 2% @ 1kHz

• Midrange Speakers: 2 x 43 mm drivers, 4W each, THD < 2% @ 1kHz

• Speaker Sampling Rate: 48 kHz

Microphones:

• Pickup Range: Up to 7 m

• 6 omnidirectional digital MEMS microphones forming 5 adaptive beams

• Frequency Response: 90Hz – 16kHz

• Sensitivity: > -36dBFS ±1 dB @ 1Pa

• Audio Processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)

• AI-based noise suppression

• Supports up to 3 Rally Mic Pods & 2 Mic Pod Hubs for larger rooms

RightSense™ Technologies:

• RightLight: Natural skin tones in all lighting conditions

• RightSight: AI-driven framing of active speakers & full-room view

• RightSound: Levels voices, suppresses background noise

• Grid View: Frames all participants for equitable hybrid meetings

Interfaces:

• HDMI Out: 2 (up to 1080p)

• HDMI In: 1

• USB: 3 x Type-A, 1 x Type-C

• Network: 10/100/1G Ethernet

• Wi-Fi: 802.11 a/b/g/n/ac

• External Mic Input (proprietary Rally Mic Pod connector)

• Remote Control: Bluetooth® Low Energy

Power & Cables:

• Auto-sensing power supply: 100–240V, 19V, 4.74A

• DC Cable: 1.5 m | AC Cable: 1 m

• HDMI 1.4 Cable: 2 m | USB-A to USB-C 3.0 Cable: 2.2 m

Environmental:

• Operating Temp: 0° to 40°C

• Storage Temp: -40° to 70°C

• Humidity: 10–95%

• BTU/hr: 57 idle, 64 in meeting

Security:

• Full Disk Encryption: AES-128

• Data Encryption: Symmetric Keys, PKI

• Device Identity: Protected by device attestation

• Key Protection: Arm TrustZone, RPMP

Accessories (Optional):

• Wall Mount for Video Bars, TV Mount for Video Bars

• Rally Mic Pod, Rally Mic Pod Hub, Mic Pod Mount & Extension Cable

• Logitech Strong USB (10m, 25m, 45m)

• Logitech Tap & Tap IP touch controllers

Device Management:

• Logitech Sync for remote management & monitoring

Compatibility:

• USB Mode: Windows 10/11, macOS (latest two versions)

• Appliance Mode: Room solution software license (not included)

• Wired or wireless internet connection required

Warranty:

• Standard: 2-year limited hardware warranty

• Optional: +1-year or +3-year extended warranty (purchased with device)
