Panel

• Screen Size: 55″ (139 cm)

• Panel Technology: ADS

• Resolution: 3840 x 2160 (UHD)

• Brightness: 400 nit (Typ.)

• Refresh Rate: 60Hz

• Contrast Ratio: 1,000,000:1 (Dynamic)

• Color Depth: 1.07B (8bit + FRC)

• Viewing Angle: 178° x 178°

• Response Time: 8ms (G to G)

• Operation Hours: 16/7

• Orientation: Portrait / Landscape

Connectivity

• HDMI In: 3 (HDCP 2.2/1.4)

• USB: 2 × USB 2.0 Type-A

• Audio Out: Yes

• RS232C: In/Out

• RJ45 LAN: 1 Input

• Wi-Fi (Built-in): Yes

• Daisy Chain: No

Mechanical

• Bezel Width (Off): 6.9 mm (top/sides), 18.4 mm (bottom)

• Weight: 14 kg (head), 18.8 kg (packed)

• Dimensions: 1235 × 715 × 57.5 mm

• VESA Mount: 300 × 300 mm

• Bezel Color: Ashed Blue

Software & OS

• OS Version: webOS 6.0

• Internal Memory: 16 GB eMMC

• Features:

  • Local Content Scheduling

  • Screen Share & Rotation

  • Video Tagging (4 tags)

  • Fail Over, SNMP, Wake-on-LAN

  • SuperSign CMS, Control+, WB

  • Control Manager & Status Mailing

  • Brightness & Auto Sensors

  • Cisco Certified, Crestron Connected

Power & Efficiency

• Power Supply: 100–240V~, 50/60Hz

• Typical Power: 105 W

• Max Power: 160 W

• Smart Energy Saving: 73.5 W

• Power Off: 0.5 W

• DPM Mode: 0.5 W

Audio

• Built-in Speakers: 2 × 10 W

Certifications

• Safety: CB

• EMC: FCC Class “A” / CE

• Energy Efficiency: Energy Star Compliant

Included Accessories

• Remote Control (w/ 2 Batteries)

• Power Cord

• Regulation Book

• D-Sub9 Gender Adapter

• Cable Holder
