Display

• Screen Size: 43″ (109.22 cm)

• Panel Type: IPS, Direct LED Backlight

• Resolution: 3840 × 2160 (UHD)

• Aspect Ratio: 16:9

• Brightness: 500 nits (Typ.)

• Dynamic Contrast Ratio: 1,000,000:1

• Color Gamut: BT709 95%

• Color Depth: 8-bit + FRC, 1.07 Billion colors

• Response Time: Rise: 8ms / Fall: 10ms

• Viewing Angle: 178° × 178°

• Surface Treatment: 28% Haze

• Orientation: Portrait and Landscape

• Operation: 24/7 rated

Connectivity

• HDMI In: 3 ports (3840×2160@60Hz, HDCP 2.2/1.4)

• DP In: 1 port (3840×2160@60Hz, HDCP 2.2/1.3)

• USB: 1 × USB 2.0 Type A

• RS232C In/Out: Yes (4-pin Phone-jack)

• LAN (RJ45): Yes

• IR In: Yes

• Audio Out: Yes

• HDMI Out: 1 port (3840×2160@30Hz)

• External Speaker Out: Yes

• Daisy Chain Support: Yes (via HDMI & DP)

Mechanical

• Bezel: T/B: 12.1mm | R/L: 11.1mm (Black)

• Dimensions (W × H × D): 968 × 559 × 57.7 mm

• Weight: 9.0 kg (Net), 11.3 kg (Packed)

• VESA Mount: 200 × 200 mm

Software & Features

• Operating System: webOS 6.0

• Internal Memory: 16 GB eMMC

• Sensors: Temperature, Auto Brightness (IR), Accelerometer

• PIP / PBP / Tile Mode: Yes (Tile up to 15×15)

• Smart Features:

  • Screen Share, Rotation, Fail Over, Wake on LAN

  • SNMP, RS232C Sync, HDMI-CEC, Smart Energy Saving

  • Cisco Certified, Crestron Connected, BEACON support

Power

• Power Supply: AC 100-240V, 50/60Hz (Built-in)

• Typical Consumption: 110W

• Max Consumption: 140W

• Power Saving (70%): 70W

• Standby: 0.5W

Environmental

• Operating Temp: 0°C to 40°C

• Humidity: 10% to 80%

• IP Rating: IP5x

• Tilt Support: Yes (Up to 30°, max 40°C)

• Conformal Coating: Yes (Power Board)

Certifications

• Safety: CB / NRTL

• EMC: FCC Class B / CE / KC

• Energy: NewErP / Energy Star

Accessories

• Included: Remote Control (with batteries), Power Cord, QSG, Regulation Book, RS232C Adapter

• Optional: Slim Wall Mount (WB21LMA/B), Wall Mount (LSW240A/B)
