• Brilliant Visual Performance – 3,700 lumens colour & white brightness with crisp WXGA resolution.

• Vibrant & Accurate Colours – 3LCD technology provides equal white and colour light output for natural images.

• Big-Screen Impact – Achieve displays up to 320 inches, ideal for presentations, video conferencing, or training sessions.

• Long Lamp Life – Up to 12,000 hours in Eco Mode, minimising downtime and cost.

• Flexible Connectivity – HDMI, USB, VGA, and composite video inputs.

• Optional Wireless Capability – Add the ELPAP11 adapter for Wi-Fi and iProjection app compatibility.

• Quick Setup – Keystone correction and Quick Corner make alignment simple and fast.

---

Technical Specifications

Projection Technology:

• 3LCD, RGB liquid crystal shutter system

Image Quality:

• Brightness: 3,700 lumens (colour/white)

• Resolution: WXGA (1280 x 800)

• Contrast Ratio: 16,000:1

• Aspect Ratio: 16:10

• Screen Size: 33” – 320”

• Colour Light Output: Equal to White Light Output for balanced, vivid colours

Lens & Image:

• Zoom: Manual, 1.2x

• Focus: Manual

• Throw Ratio: 1.30 – 1.56 (Wide to Tele)

• Focal Length: 16.90 – 20.28 mm

• F-number: 1.49 – 1.72

Lamp:

• Type: 210W UHE

• Life: 6,000 hours (Normal) / 12,000 hours (Eco)

Keystone Correction:

• Vertical ±30° (auto)

• Horizontal ±30°

• Quick Corner feature for precise alignment

Connectivity:

• HDMI: 1

• VGA (D-Sub 15-pin): 1

• Composite Video: 1 RCA

• Audio Input: 2RCA (White & Red)

• USB: Type-A (1), Type-B (1)

• Wireless LAN: Optional (via ELPAP11 adapter)

Optional Wireless Specs:

• IEEE 802.11 a/b/g/n (2.4GHz & 5GHz)

• WPA2/WPA3-PSK security

General Specs:

• Dimensions (W x D x H): — (similar class units: approx. 302 x 234 x 77 mm)

• Weight: ~2.8–3.0 kg

• Air Filter: High Efficiency Filter (6,000 / 12,000 hours maintenance cycle)

• Operating Altitude: 0–3,048 m (0–10,000 ft)

• Start-Up Time: 6 seconds (warm-up: 30 seconds)

• Direct Power On/Off: Supported
