• Image Sensor: 1/1.8” 4MP Progressive Scan CMOS (1.411 cm)

• Max Resolution: 4MP (2688 × 1520) @ 1–25/30 fps

• Compression Formats: Instastream, H.265, H.264, H.264H, H.264B, MJPEG

• Streaming: Penta stream support

• Lens: 3.6mm fixed lens (2.8mm optional)

• Illumination Range:
  • IR: Up to 50m
  • Warm Light: Up to 50m

• Audio: Built-in microphone

Core Features

✔ Dual Light Technology – Switches between IR and warm light for optimal surveillance at night.
✔ Wide Dynamic Range (120dB) – Captures clear images in challenging light conditions.
✔ Smart Video Enhancements: 3D NR, AWB, AGC, BLC, HLC, ROI, Digital watermarking.
✔ Penta Stream – Flexible streaming for diverse network setups.
✔ Integrated Audio: Built-in mic for capturing on-site sound.
✔ Rugged Durability: IP67 weatherproof enclosure ensures reliable outdoor performance.
✔ Onboard Storage: Micro SD card slot for local recording.
✔ PoE Support: Simplifies installation using a single cable for power and data.
✔ SMD 4.0 (Smart Motion Detection): Reduces false alarms by intelligently identifying human and vehicle movement.

Technical Details

Day/Night Mode: ICR (Infrared Cut Filter)
Frame Rate: Up to 30 fps @ 4MP
Network Protocols: ONVIF compliant
Power Supply: PoE (Power over Ethernet)
Environmental Rating: IP67 (weatherproof)

Ideal Applications

• Outdoor perimeter security for factories & warehouses

• Parking lots & commercial complexes

• Public spaces (streets, parks, community areas)

• Industrial & construction sites

• Residential complexes requiring robust bullet surveillance
