Display

• Screen Size: 75” UHD (3840 × 2160)

• Panel Type: IPS, Landscape orientation

• Brightness: 450 nits (typ.)

• Contrast Ratio: 1200:1 (typ.), 30,000:1 (dynamic)

• Color Depth: 10-bit

• Color Gamut: 72% NTSC

• Response Time: 8 ms

• Backlight Life: 50,000 hours

Touch & Surface

• Touch Technology: High Precision IR, 40 touch points

• Touch Response: < 10 ms

• Glass: 9H tempered, anti-glare, germ-resistant nano-ionic silver coating

System

• Operating System: Android 11.0

• CPU: Octa-core (A73 × 4 + A53 × 4)

• GPU: G52 MP8

• RAM | Storage: 8 GB | 64 GB

Connectivity

• HDMI: 3 in (2.0) | 1 out (2.0)

• VGA: 1 | DisplayPort: 1 (1.2a)

• USB: 2 × USB 2.0, 5 × USB 3.0, 1 × USB-C (PD 65W), 1 × USB-C (3.0)

• USB-B (for touch): 3 × USB 3.0

• Audio: Mic × 1, Line in × 2, Line out × 1, Earphone × 1

• RS-232: 1 | Ethernet: 2 × Gigabit LAN

• Wi-Fi: Built-in

• S/PDIF: Optical × 1

• OPS Slot: 1

Built-in Features

• Speakers: 2 × 16W + 1 × 16W subwoofer

• Microphone: 8-microphone array (range up to 8 m)

• NFC Sensor | Ambient Light Sensor | Motion Sensor

• Air Ionizer | TVOC Air Sensor

Power

• Power Supply: AC 100–240V, 50/60Hz

• Power Consumption: 90.1 W (typ.), < 0.5 W (standby)

Dimensions & Weight

• Product Dimensions (W × H × D): 1717.1 × 1065.3 × 121.7 mm

• Shipping Dimensions: 1900 × 1160 × 225 mm

• Weight: 55.5 kg (product) | 70 kg (shipping)

• VESA Mount: 800 × 400 mm

Environment

• Operating Temp: 0°C ~ 40°C

• Storage Temp: -10°C ~ 60°C

• Operating Humidity: 20% ~ 80% RH (non-condensing)

Software & Tools

• Whiteboarding: EZWrite 6.0

• Wireless Sharing: InstaShare 2

• Device Management: DMS

• Account Management: AMS

• Broadcast: X-Sign Broadcast

• Tools: Floating Tool, Flicker-Free, Low Blue Light

Accessories Included

• Cables: VGA, HDMI, USB-B, USB-C

• Wall Mount: 1 set

• Remote Control: 1

• Pens: 2
