Display

• Screen Size: 98″

• Panel Type: IPS, UHD (3840 × 2160)

• Brightness: 500 nits

• Contrast Ratio: 1200:1 (Typical), 30,000:1 (Dynamic)

• Response Time: 8 ms

• Orientation: Landscape

• Color Gamut: 68% NTSC

• Operation Hours: 18/7

• Glass: 9H tempered, anti-glare, germ-resistant

• Backlight Life: 50,000 hours

Touch & Input

• Touch Technology: Precision IR

• Touch Points: Up to 40

• Touch Response: < 5 ms

System

• OS: Android 13.0

• CPU: Quad-core A73 + Quad-core A53

• GPU: G52 MP8

• Memory & Storage: 8 GB RAM | 64 GB ROM (expandable up to 512 GB)

Connectivity

• HDMI: 3 in (2.0), 1 out (2.0)

• VGA: 1

• DisplayPort: 1 (1.2)

• USB: 2 × USB-A 2.0, 2 × USB-A 3.0, 1 × USB-C 2.0, 1 × USB-C 3.0 (PD 65W)

• USB-B for Touch: 2 × 2.0

• Micro SD: 1 (up to 512 GB)

• Audio: PC Audio In, Mic In, Earphone Out, S/PDIF Optical Out

• Network: Dual Gigabit Ethernet (Android + OPS)

• RS-232: 1

• OPS Slot: 1

Audio & Visual

• Microphone: 8-microphone array (range up to 8 m)

• Speakers: 2 × 20W

• Camera: 1 (Built-in)

Built-in Sensors

• NFC, IR, Ambient Light

Power

• Power Input: AC 100-240V 50/60Hz

• Typical Power Use: 122.7 W

• Standby: < 0.5 W

• ENERGY STAR® Certified: Yes

Dimensions & Weight

• Dimensions (W×H×D): 2230.8 × 1335.9 × 103.1 mm

• Weight: 104.75 kg (product), 134.65 kg (shipping)

• Mount: VESA 800 × 600 mm

Environment

• Operating Temp: 0°C ~ 40°C

• Storage Temp: -10°C ~ 60°C

• Humidity: 20–80% operating, 10–80% storage (non-condensing)

Software & Features

• Whiteboarding: EZWrite 6.0

• Wireless Sharing: InstaShare 2

• Device Management: DMS

• Account Management: AMS

• Tools: Floating Tool, X-Sign Broadcast

• Eye Care: Flicker-Free, Low Blue Light

Included Accessories

• Cables: VGA, HDMI, USB-B, USB-C (varied lengths)

• Wall Mount: 1

• Pens: 2

• Remote Control: 1
